N Male Right Angle to SMA Female Cable Assembly using LC085TBJ Coax, 1 FT

These high-quality RF coax cable assemblies can be used for telecom, military / defense, laboratory test & measurement, industrial / commercial and many other applications. These RF coaxial cable assemblies are built with right angle N connection on one end and SMA connection on the other. This right angle N to SMA cable from L-com has a male to female gender combination. This N male to SMA female coaxial assembly part number LCCA30614-FT1 can also be known as right angle N plug to SMA jack cable assembly when using alternate gender names.

N plug to SMA jack cable assembly LCCA30614-FT1 is manufactured with a formable coax. These formable N to SMA cable assemblies use LC085TBJ coax and are single shielded. Maximum frequency for these N to SMA M/F cables is 10 GHz. This product can also be called a SMA female to right angle N male cable assembly because it can be used in the opposite direction.

Features

• Max Frequency 10 GHz
• Shielding Effectivity > 100dB
• PTFE Dielectric with 69.5% VoP
• Hand Formable
• Tin Filled Copper Composite Braid Outer Conductor
• FEP Jacket

Application

• General Purpose
• Laboratory Use
• System Interconnect
