RF Attenuators

L-com's LCMP1100 is a 50 ohm BNC male to 75 ohm BNC female matching pad that operates from DC to 3 GHz. This BNC to BNC impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1100 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1106 is a 50 ohm N female to 75 ohm F female matching pad that operates from DC to 3 GHz. This N to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1106 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1104 is a 50 ohm N female to 75 ohm F male matching pad that operates from DC to 3 GHz. This N to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1104 50 ohm to 75 ohm minimum loss pad has a maximum...

L-com's LCMP1105 is a 50 ohm N female to 75 ohm N female matching pad that operates from DC to 3 GHz. This N to N impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1105 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1103 is a 50 ohm N male to 75 ohm F female matching pad that operates from DC to 3 GHz. This N to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1103 50 ohm to 75 ohm minimum loss pad has a maximum...

L-com's LCMP1101 is a 50 ohm N male to 75 ohm N female matching pad that operates from DC to 3 GHz. This N to N impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1101 50 ohm to 75 ohm minimum loss pad has a maximum...

L-com's LCMP1109 is a 50 ohm SMA female to 75 ohm F female matching pad that operates from DC to 3 GHz. This SMA to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1109 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1108 is a 50 ohm SMA male to 75 ohm F female matching pad that operates from DC to 3 GHz. This SMA to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1108 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1107 is a 50 ohm SMA male to 75 ohm F male matching pad that operates from DC to 3 GHz. This SMA to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1107 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1110 is a 50 ohm TNC female to 75 ohm F female matching pad that operates from DC to 3 GHz. This TNC to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1110 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1111 is a 50 ohm TNC female to 75 ohm F male matching pad that operates from DC to 3 GHz. This TNC to F impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1111 50 ohm to 75 ohm minimum loss pad has a...

L-com's LCMP1102 is a 50 ohm N female to 75 ohm N male matching pad that operates from DC to 3 GHz. This N to N impedance matching pad offers a low VSWR of 1.25:1 max and attenuation of 7.5 dB max. LCMP1102 50 ohm to 75 ohm minimum loss pad has a maximum...
