2.4/5 GHz 9 dBi Flat Panel Antenna - N-Female Connector

The HG2458-09P is a high performance multi-band directional flat patch WiFi antenna suitable for indoor and outdoor applications in the 2.4GHz (2400-2500 MHz) and 5 GHz (5125-5850 MHz) band. The Multi-Band design of this antenna eliminates the need to purchase different antennas for each frequency. This simplifies installations since the same antenna can be used for a wide array of wireless applications. This WiFi antenna is lightweight and features an aesthetic UV-stable, UL flame rated white plastic radome which can also be painted to match the room or building structure. It features a integral N-Female connector.

Multi-Band Operation

• The HG2458-09P is actually two antennas in one. A dual element 2.4 GHz antenna and a dual element 5 GHz antenna coupled to a single feed. Since many multi-band 802.11a/b/g radios share a single antenna, the HG2458-09P can split these signals so that the two separate internal 2.4 GHz and 5 GHz antennas can be used to improve performance. The HG2458-09P can also receive separate 2.4 GHz and 5 GHz signals and combine them into a single feed.

The HG2458-09P antenna is supplied with a 60 degree tilt and swivel mast mounting kit. This antenna can be wall mounted with the optional brackets.

Features

• Multi-Band operation - 2400-2500 MHz and 5125-5850 MHz
• Can be installed for either vertical or horizontal polarization
• Dual element 2.4 GHz and 5 GHz internal antennas coupled to a single feed
• Durable UV-stable, UL flame rated radome
• Light weight, Low loss solid brass elements & integral N-Female connector

Application

• IEEE 802.11a/b/g/n and 802.11ac applications
• 2.4 GHz and 5.8 GHz wireless video systems
• 2.4 GHz ISM, 5.3 GHz and 5.8 GHz UNII/ISM band wireless systems
• 2.4/4.9/5.1/5.3/5.4/5.8 GHz Wireless LAN systems
• WiFi and WiMAX applications
