When traditional splitters do not fit, L-com's exclusive shielded Y-adapter series is perfect. These splitters feature a 10" shielded cable for the male plug and a unique housing for the two shielded RJ45 jacks allowing this adapter to plug into tight spaces without blocking adjacent ports. The light gray plastic housing is UL94V-0 rated and features a wiring diagram for easy port identification. L-com stocks three different wiring schemes for either USOC bridge/splitter or a 10Base-T splitter, or we can quote a custom version with modest minimums.

Features

• Light gray plastic housing is UL94V-0 rated and features a wiring diagram for easy port identification
• Three different wiring schemes for either USOC bridge/splitter or a 10Base-T splitter
• Most common configurations available from stock for fast delivery
• Shielded 10" cable length to reach into tight spaces
• Shielded 2-way modular Y-adapters/splitters for voice and data applications

Application

• LAN
• Signal sharing/splitting
• Voice/data

Downloads:

• 2D Drawing (.pdf)
• 3D CAD Model (.step)
