SMA Male Right Angle to N Male Cable Assembly using LC141TB Coax, 6 FT

These high-quality RF coax cable assemblies can be used for telecom, military / defense, laboratory test & measurement, industrial / commercial and many other applications. These RF coaxial cable assemblies are built with right angle SMA connection on one end and N connection on the other. This right angle SMA to N cable from L-com has a male to male gender combination. This SMA male to N male coaxial assembly part number LCCA30411-FT6 can also be known as right angle SMA plug to N plug cable assembly when using alternate gender names.

SMA plug to N plug cable assembly LCCA30411-FT6 is manufactured with a formable coax. These formable SMA to N cable assemblies use LC141TB coax and are single shielded. Maximum frequency for these SMA to N M/M cables is 10 GHz. This product can also be called a N male to right angle SMA male cable assembly because it can be used in the opposite direction.

Features

• General Purpose
• Laboratory Use
• System Interconnect

Application

• Max Frequency 10 GHz
• Shielding Effectivity > 100dB
• PTFE Dielectric with 69.9% VoP
• Hand Formable
• Tin Filled Copper Braid Outer Conductor

Downloads:

• Datasheets
• 3D CAD Model (.step)
