SCSI-3 Cable, HPDB68 Male / Male w/Ferrites, 1.0m

SCSI-3 cables from L-com are manufactured to meet or exceed SCSI standards. Connectors are half pitch 68 position male on both ends with rugged molded backshells plus two ferrite cores. The ferrite cores help reduce radiated emissions and undesirable currents within the shield. Features double shielded cable (copper braid plus aluminum mylar foil) and 34 pair 28 AWG conductors for the highest quality.

Thumbscrews are 2-56 threaded to fit most applications. Twisted pair cabling reduces cross talk.

Features.

• Ferrite beads reduce radiated emissions and undesirable currents within the shield
• Gold plated contacts insure repeated mating cycles
• HPDB68 position male connectors; length options are 0.5, 1, 2 & 3 meters; color is light gray
• Molded backshells provide durability and increased strength at cable entry point
• Meets or exceeds SCSI specifications

.

Application

• Storage applications
• Data transfer
• Hard disk drives

Downloads:

• Tips
• 2D Drawing (.pdf)
• 3D CAD Model (.step)
