N Male Right Angle to SMA Male Right Angle Cable Assembly using LC085TB Coax, 1.5 FT

These high-quality RF coax cable assemblies can be used for telecom, military / defense, laboratory test & measurement, industrial / commercial and many other applications. These RF coaxial cable assemblies are built with right angle N connection on one end and right angle SMA connection on the other. This right angle N to right angle SMA cable from L-com has a male to male gender combination. This N male to SMA male coaxial assembly part number LCCA30544-FT1.5 can also be known as right angle N plug to right angle SMA plug cable assembly when using alternate gender names.

N plug to SMA plug cable assembly LCCA30544-FT1.5 is manufactured with a formable coax. These formable N to SMA cable assemblies use LC085TB coax and are single shielded. Maximum frequency for these N to SMA M/M cables is 10 GHz. This product can also be called a right angle SMA male to right angle N male cable assembly because it can be used in the opposite direction.

Features

• Max Frequency 10 GHz
• Shielding Effectivity > 100dB
• PTFE Dielectric with 69.5% VoP
• Hand Formable
• Tin Filled Copper Composite Braid Outer Conductor

Application

• General Purpose
• Laboratory Use
• System Interconnect

Downloads:

• Datasheets
• 2D Drawing (.pdf)
• 3D CAD Model (.step)
