M12 8 Position A-code Shielded Industrial Outdoor Assembly, PVC Jacket, M/F, Gray, 3.0M
M12 8 Position A-code Shielded Industrial Outdoor Assembly, PVC Jacket, M/F, Gray, 3.0M

M12 8 Position A-code Shielded Industrial Outdoor Assembly, PVC Jacket, M/F, Gray, 3.0M

$86.99
$82.64
{"without_tax":{"formatted":"$82.64","value":82.64,"currency":"USD"},"tax_label":"Tax","rrp_without_tax":{"formatted":"$86.99","value":86.99,"currency":"USD"},"saved":{"formatted":"$4.35","value":4.35,"currency":"USD"}}
(You save 5.00% )
SKU: TRG884-C6G-3M
Lead Time (Days): 55
Weight: 0.480000 LBS
Country of Origin: CN
Schedule B: 8544422000
ECCN: EAR99
Adding to cart… The item has been added
Description

L-com stocks 8 Position A-coded M12 cable assemblies for use in sensor, actuator or Fieldbus applications. The single keyway A-code M12 connectors are IP67 rated when mated and are excellent for lock-down applications. All cables have moisture and sunlight resistant jackets. PUR versions have additional chemical and industrial resistances while PVC versions have a high +105°C temp range. All assemblies have UL recognized jackets and a VW-1 flame rating.

Features

  • UL Style 2517 PVC jacket is resistant to moisture, sunlight (UV) and has a flame rating of VW-1
  • M12 connectors are threaded and IP67 rated when mated properly
  • PVC jacket has a robust temperature range of -25°C to +105°C and is built with 26AWG stranded conductors for flexibility
  • This assembly is straight wired and shielded for EMI/RFI protection
  • Used to connect to M12 devices that utilize an 8 position, A-code (single keyway) connector

Application

  • I/O connectivity
  • Field Bus and CAN bus
  • Food and beverage services
  • Motion controller, factory automation and industrial control
  • Sensors and actuators
