Low Loss SMA Male to Reverse Polarity TNC Plug Cable Assembly using CA-195R Coax, 10 FT

Customers designed the L-com CC-SMRTPA010 low loss SMA Male to Reverse Polarity TNC Plug high running RF cable assembly with CA-195R, which we now offer as a standard. This flexible 50 Ohm low loss cable is intended for use in laboratories, universities, communications, aerospace, and military defense sectors. This RF cable is constructed with a solid copper center conductor and a PE dielectric, making it perfect for installers, manufacturers, and prototypes. This black RF cable assembly features a PVC (FR) jacket with a diameter of 0.195 inches. The CC-SMRTPA010 SMA Male to Reverse Polarity TNC Plug low loss cable assembly has a maximum frequency of 5.8 GHz.

This between series cable assembly's maximum VSWR is 1.5:1. The L-com RF cable assembly is 10 feet long, with a minimum bend radius of 1 inch for single bends and 2 inches for repeated bends. This cable's low-loss construction reduces signal attenuation, with typical insertion losses ranging from 0.770 dB/ft at 250 GHz to 3.190 dB/ft at 5.8 GHz. This 10-foot CA-195R cable assembly has an 80% velocity of propagation and a minimum RF shielding of 90 dB.
