Low Loss N Male to Reverse Polarity SMA Plug Cable Assembly using CA-240 Coax, 3.333333 FT

This item may be subject to additional Tariff Surcharge Tariff Surcharge Section 301 USTR Import Tariff related to this product. This product may have a surcharge if the product is shipped to an address within the United States. This surcharge will be finalized after the shipping Address information is entered on the Check Out page. of $2.55 (5%) each.

Customers designed the L-com CC-NMRSPTN40 low loss N Male to Reverse Polarity SMA Plug high running RF cable assembly with CA-240, which we now offer as a standard. This flexible 50 Ohm low loss cable is intended for use in laboratories, universities, communications, aerospace, and military defense sectors. This N Male to Reverse Polarity SMA Plug cable assembly includes 50 Ohm connectors on both ends with crimp attachments and gold-plated brass contacts. This RF cable is constructed with a solid copper center conductor and a PE dielectric, making it perfect for installers, manufacturers, and prototypes. This black RF cable assembly features a PE jacket with a diameter of 0.240 inches.

The CC-NMRSPTN40 N Male to Reverse Polarity SMA Plug low loss cable assembly has a maximum frequency of 5.8 GHz. This between series cable assembly's maximum VSWR is 1.5:1. The L-com RF cable assembly is 3.33 feet long, with a minimum bend radius of 1.2 inch for single bends and 2.5 inches for repeated bends. This 3.33-foot CA-240 cable assembly has an 84% velocity of propagation and a minimum RF shielding of 90 dB.

Downloads:

• 2D Drawing (.pdf)
