Fiber Optic Patch Cable SMA/PC-FC/PC Duplex 50/125 OM5 Multimode Fiber 3.0mm PVC Jacket 5 meters

The L-com FCA-SMPFCP-DPM5V-05 is a Duplex OM5 Multimode Fiber optic patch cord with SMA/PC to FC/PC connectors with a cable length of 5 meters.

The SMA Connector, also known as the SMA905 or FSMA Connector, was one of the first fiber optic interconnect system that gained industry wide acceptance. Today's L-com FCA-SMPFCP-DPM5V-05 is optimized for military, industrial and medical applications with the highest quality OM5 Multimode Fiber and protected by the industry's best 3.0mm PVC jacket. The L-com FCA-SMPFCP-DPM5V-05 offers performance characteristics of ≤0.2dB for Insertion Loss and a typical Return Loss of ≥30dB at Operating Wavelength of 850nm/1300nm making the L-com FCA-SMPFCP-DPM5V-05 an ideal choice for designs requiring threaded fiber optic interconnects.

Now you have a reliable, compatible and affordable means to expand your fiber optic designs and products while maintaining its integrity.

Features

• Precision Performance Characteristics - Insertion Loss ≤0.2dB; Return Loss ≥30dB
• Duplex Clip Prevents the Fiber from Rotating and Maintains the Polarity
• A Wideband OM5 Multimode Fiber Solution, supporting Operating Wavelength 850nm/1300nm
• Durable and Reliable
• Custom lengths and configurations available

Application

• Medical Technology
• High-power coupling
• Data and video Transmission
• Industrial Spectroscopy
• Legacy Military
• Photonics

Downloads:

• 2D Drawing (.pdf)
