DUO5 Positioner

This item requires a custom order, please call us.

The DUO series positioners from MmWaveTest are dual-armed antenna positioners designed with precision and quality in mind. By mounting the DUT on the plate in the dual-arm setup, the DUO positioners can handle a high load in a small form factor. This is ideal to test heavy devices accurately in small anechoic chambers. All DUO positioners use instrument-grade azimuth and roll drives with strength, high repeatable precision, and low backlash. They are built with quality in mind to ensure longevity even under high load in daily use. This DUO5 is a large-scale positioner designed for over-the-air (OTA) antenna measurements. With a total arm width of 70 cm, it can be used in walk-in and medium-sized desktop anechoic chambers. Mounted on an azimuth platform with built-in slipring, the dual-arm design has both motors at the base to minimize stray reflections near the DUT.

Supports DUTs up to 14 kg (32 lb.,) a width of 50 cm (20" ), and a depth of up to 20 cm (8").

Delivered with

• 260 W 100-240V power supply
• Multi-axis controller
• Power and control cabling
• Python application to get you started measuring in short time.

Downloads:

• DUO5 product sheet (.pdf)
