1.0/2.3 Plug Low PIM Connector Solder Attachment for TFT-402, TFT-402-LF

L-com's 1.0/2.3 Plug Low PIM Connector Solder Attachment for TFT-402, TFT-402-LF uses a solder/solder attachment method. This 1.0/2.3 Plug connector operates up to a maximum frequency of 6 GHz. L-com's portfolio of RF and microwave connectors allows users to choose from a large number of options when building connectorized cable assemblies to fit their RF interconnect needs. RF cables can be created to fulfill many interconnect applications ranging from In the Box hookup, to connectivity with test equipment or as part of a system installation. In addition to this offering of RF connectors and coaxial cable, L-com also offers both standard and custom cable assemblies to fit your specific needs.

Features

• Operating Frequency up to 6 GHz
• VSWR Rating of 1.3:1
• PIM levels better than -150 dBc
• Brass Contact with 200 µin Silver Plating

Application

• General Purpose Test
• Wireless Communications
• Custom Cable Assemblies
• Low PIM Applications
• Distributed Antenna Systems (DAS)

Downloads:

• Datasheets
• 3D CAD Model (.step)
